- Commodity name: Vehicle-Mounted Hydraulic Large Displacement Hose Reel
- Commodity ID: EB800HPRSH
- Item No.: EB800HPRSH020D08CS
- Reel Weight: 287
- Hose I. D.: 7 7/8
- Max Hose Length: 82
- Hose O. D.: 8.425
- Size Index: 1
- Power Type: Hydraulic Driven
- Note: Product customization is acceptable
EB800 Series vehicle-mounted hydraulic large displacement hose reel realizes rewinding and reeling through hydraulic motor, Cooperate with professional emergency drainage vehicles, remote water supply vehicles, mobile skid-mounted water pump stations etc.

It can be used for drainage and water supply in areas without fixed pumping stations and no power sources , city streets and highway tunnels drainage, emergency water supply for fire fighting, flood control and drainage, drainage of submerged areas in communities, rivers, lakes, reservoirs, marine water environment treatment, agricultural irrigation, and drought-resistant water supply , Temporary water transfer and other areas of the water supply pipeline, after using, can quickly rewind, convenient transportation and storage, and increase the service life of the hose.
Key words:
- hydraulic
- drainage
- temporary
- firefighting
- Sewage
1. Large discharge

2. Safe and convenient operation

Model	Reel Weight		HOSE I.D.		HOSE O.D.		Max Hose Length		Size Index
	kg	lbs	mm	Inch	mm	Inch	m	ft
EB800HPRSH020D08CS	130	287	200	7 7/8	214	8.425	25	82	1
If you want to replace other hose models and lengths, please consult the sales dealer or sales engineer
