- Commodity name: Vehicle-Mounted Wind Power Oil Changing And Oil Filling Hose Reel
- Commodity ID: EB1200HPRDH020CC
- Item No.: EB1200HPRDH020CC
- Reel Weight: 573
- HOSE I.D. 1: 3/4
- HOSE O.D. 1: 1.201
- HOSE I.D. 2: 1
- HOSE O.D. 2: 1.441
- Hose Outlet2: M36X1.5
- Hose Outlet1: M22X1.5
- Reel Inlet: G1-1/4
- Driven Type: Hydraulic Driven
- Max Hose Length: 262
- Size Index: 1
Vehicle-mounted wind power oil changing and oil filling hose reel is a gearbox maintenance oil changing and oil filling equipment specially designed for wind power equipment,

Vehicle-mounted oil pump sucks the wind power gear box oil that needs to be replaced into the oil tank on the vehicle through the hoses in one of the reels, oil filling pump is connected with the second hose in the reel to injection clean lubricating oil into the wind power gearbox.

Using this type of reel greatly improves the efficiency of wind power maintenance and reduces maintenance costs.

The reel structure is manufactured in accordance with the quality standards of vehicle anti-bumps, made of high-quality steel. The hose is resistant to wear and tear, The joint adopts a 24°cone H-shaped seal to avoid and reduce oil leakage.

This product can also be flexibly used in the airport ground well fixed installation or fan oil change and other vehicle-mounted occasions.
1. The two channels are suitable for different hose specifications, better to meet the needs of the field.

2. Corrosion resistance: stainless steel or electrostatic spray treatment to prevent rust.

3. Rotating bracket and multi-position adjustable outlet make installation and use easy and quick.

Model

Reel Weight

HOSE I.D. 1

HOSE O.D.1

HOSE I.D.2

HOSE O.D.2

Hose Outlet1

Hose Outlet2

Reel Inlet

Max Hose Length

Size Index

lbs

Inch

BSP

EB1200HPRDH020CC

260

573

3/4

30.5

1.201

36.6

1.441

M22X1.5

M36X1.5

G1-1/4

262

If you want to replace other hose models and lengths, please consult the sales dealer or sales engineer

1. Post-maintenance of wind power gearboxes, daily maintenance of large mining vehicles and ships.

2. Chemical inverted transportation.

3. Engineering vehicles: grease lubrication, lubrication filling

4. Oil transportation: diesel oil transportation, engine oil, pressure oil filling.
