- Commodity name: Electro-hydraulic Integrated Hose Reel
- Commodity ID: EB500SRMH012S10CC
- Item No.: EB500SRMH012S10CC
- Reel Weight: 132
- Work Pressure: 33
- Hose I.D.: 3/8
- Hose O.D.: 0.827
- Cable Spec. : 8*1.5+4*0.75
- Max Cable Length: 39
- Driven Type: Spring Driven
- Size Index: 1
- Note: Product customization is acceptable
Construction machinery reel is also called reciprocating follow-up reel.

Often used on some mechanical telescopic arms, such as : The hydraulic hose of the luffing cylinder of the crane, Signal cable on mechanical telescopic arm, Power cable, Compressed air hose, The shield segment anchors the robotic arm.

The retracting method of the engineering reciprocating reel is to follow the telescopic variable distance of the robotic arm. Thereby, the medium and signal transmission problems of this kind of equipment are well solved.
1. Construction machinery reels generally have two-way hoses, three-way hoses and more than four-way hoses.

2. It can also have several functions such as hoses and cables at the same time, Usually called electro-hydraulic integrated follow-up reel.

3. This type of reel generally needs to be customized according to the actual equipment requirements of the customer.

Model

Reel Weight

HOSE I.D.

HOSE O.D.

Cable Spec.

Work pressure

Maximum cable length

Size Index

lbs

Inch

Mpa

EB500SRMH012S10CC

132

3/8

0.827

8*1.5+4*0.75

If you want to replace other hose models and lengths, please consult the sales dealer or sales engineer

Cranes, pavers, milling machines, excavators, stretchers, road recycling equipment, sweepers, drainage vehicles, dredging vehicles, fire trucks, shield machines, wet spraying machines etc.
