- Commodity name: EB480 Stainless Steel Hand Roll Hose Reel
- Commodity ID: EB480MRSH020D
- Item No.: EB480MRSH020D
- Reel Weight: 44
- Max Pressure: 5076
- Hose I.D.: 1/2
- Hose O.D.: 1.575
- Hose Outlet: M36X1.5
- Reel Inlet: M36X1.5
- Max Hose Length: 66
- Driven Type: Hand Crank
- Size Index: 1
- Note: Product Customization is acceptable
Ebenalp Sainless Steel Hose Reels is made of SS304 and SS316 material.

Using Ebenalp corrosion-resistant stainless steel reels will extend the life of hoses used for delivering chemical fluid or for cleaning.

By properly storing unused hoses, it can reduce tripping accidents caused by disorderly storage of hoses, at the same time it can improve the working environment.

Stainless steel hose reels have widely application , such as : food production、cleaning , delivery chemical fluid and industrial solvent treatment, stainless steel hose reels can also be used coastal and offshore corrosion resistant environments with demanding requirements.
1. Installed on the roller of reel outlet is convenient for retracting and unwinding operation, thus to avoid friction and reduce the hose deformation and wear.

2. The length of the tubing can be locked as required.

3. The stop function can prevent the reel from being stuck when the tubing is completely unwound.

4. Corrosion resistance: stainless steel material , prevent rust, anti-static.

5. Rotating bracket and multi-position adjustable outlet can make installation and use to be simple and quick.

6. Hose locking function.

7. Hose return Spring . the winding is smooth and strong.

Model

Reel Weight

Greatest Pressure

HOSE I.D.

HOSE O.D.

Hose Outlet

Reel Inlet

Maximum hose length

Size Index

lbs

bar

pis

Inch

BSP

EB480MRSH020D+LengthD25CC

350

5076

1/2

1.575

M36X1.5

If you want to replace other hose models and lengths, please consult the sales dealer or sales engineer

1. food production、cleaning

2. delivery chemical fluid

3. industrial solvent treatment

4. stainless steel hose reels can also be used coastal and offshore corrosion resistant environments with demanding requirements
